This digital screen maker does not need film and printing, which is simpler and more convenient than the traditional process. In addition, this digital screen printer can save costs, improve production efficiency, and help customers obtain greater benefits.
Features of Digital Screen maker
- No need for darkrooms and processing stations, and do not use to store large quantities of plates.
- The computer image is directly output, eliminating steps such as exposure and drying.
Simple operation and low cost operation. - Suitable for short-run printing and test production, fast shipment.
- Wide range of applications: clothes, gifts, prints, cups, textiles, banners and other products.
4 steps to bring your designs to life
- Finish design in computer.
- Install mesh film to screen frame.
- Start printing
- One printed screen plate is finished.
Technical Parameter of digital screen maker
| Project | AMD550A |
| Printing method | Thermal transfer |
| Print width | 300 mm |
| Print resolution | 300 dpi |
| Point density | 11.8 dots/ mm |
| The minimum inner diameter of the screen frame – the maximum width | 360- 560 mm |
| The minimum outer diameter of the screen frame – the maximum width | 440- 640 mm |
| Screen frame thickness | 25- 30 mm |
| Printing speed | MAX 10 mm/ s |
| Communication Interface | USB 2.0 full speed |
| Operating system | Windows WIN 7/ 8/ 10/ 11 |
| Power supply | 220 VAC~ 50 HZ |
| Energy consumption | 150 W |
| Working environment | Temperature: 0~30 ℃ Humidity: 20~85% RH (no condensation) |
| Storage environment | Temperature: -25~70℃ Humidity: 0~90% RH (excluding mesh, no condensation) |
| Reliability | Print head life: 20 KM |
| Physical size | 730 mm long x 200 mm wide x 200 mm high |
| Total product weight | About 22 Kg |
